Z Cardboard

Infinite Sheet / Fanfold Carton

It is a corrugated cardboard sheet that is folded into a Z shape instead of being cut to size during production, thus obtaining long lengths in an accordion form.

Haskutu A.Ş. is the leading company producing this product in Türkiye; they offer direct factory delivery from Ankara Sincan to all of Turkey with minimum orders of 2,000 m² in B, C, H, BC, EB, HE corrugated profiles ranging from 700 mm to 2,500 mm.

With a monthly capacity of 3,000 tons, production is carried out with FSC®, ISO 9001, ISO 14001 and ISO 45001 certifications.

What is Z-Cardboard?

Continuous Production Form of Corrugated Cardboard

Z-shaped corrugated cardboard is produced by folding it into a Z shape during manufacturing without cutting it to size, resulting in long, accordion-like lengths. Known as “Fanfold Carton” in Europe and America, this product is also referred to as “Endless Sheet” in Türkiye.

Precisely to your desired size on site.

The factory doesn’t have a fixed size; you cut it yourself — zero potential for waste.

One stock item, unlimited quantity.

Instead of stocking 50 separate cartons for 50 different product sizes, use a single pallet of Z-Cardboard.

Up to 30% storage space savings.

High-density storage thanks to accordion folding.

Fully compatible with automation.

The continuous form structure works integrated with automated packaging lines.

Production Capacity

With a width of 2,500 mm, we have the largest capacity for Z-shaped cardboard production in Türkiye. Direct delivery from our factory in Sincan, Ankara, to all of Turkey.

About Us

0 mm

Minimum Transverse

0 mm

Maximum Transverse

0 m²

Minimum Order

0 tons/month

Production Capacity

Which Profile, Which Job?

We manufacture in B, C, H, BC, EB, and HE wave profiles. Together, we will determine the most suitable profile for your product.
Wave
Pallet Length
Feature
Area of ​​Use
B Wave
480 m/pallet
Strong edge resistance
Horizontal boxes are suitable for products requiring frequent protection.
C Wave
360 m/pallet
The most common general-purpose profile.
Vertical lightweight products, wide range of applications.
H Wave
650 m/pallet
Highest meterage efficiency
Lightweight products, jobs where high meter yield is required.
BC Wave
212 m/pallet
Double corrugated · Maximum strength
Heavy loads, tall boxes, furniture and metal profiles.
EB Wave
325 m/pallet
High print quality
Medium-to-heavy products, print quality is important for many jobs.
HE Wave
400 m/pallet
Balanced meter/strength
Light to medium products, e-commerce and shipping.
  • Wave
  • One Palette 480m
  • Wave
  • One Palette 360m
  • Wave
  • One Palette 650m
  • Wave
  • One Palette 212m
  • Wave
  • One Palette 325m
  • Wave
  • One Palette 400m
  • Wave | Z SHIELD
  • 350m per Palette
  • Wave | Z SHIELD
  • 100m per Palette

Why Z Cardboard?

For businesses packaging products of various sizes, Z Karton offers a radical solution to the problems posed by standard corrugated cardboard.

Standard Corrugated Cardboard

  • Separate stock items for each product size.
  • Fixed dimensions at the factory — no field flexibility.
  • It requires a lot of storage space.
  • Separate ordering process for each size.
  • Need for filler material in transportation
  • Fire and waste material are high.

Z Cardboard (Infinite Sheet)

  • One-piece stock item to fit all sizes.
  • Cutting to the required dimensions on site.
  • Up to 30% storage space savings.
  • One order — logistics are simplified.
  • True to size — no extra padding needed.
  • Zero waste potential

Which sectors do we provide solutions for?

Haskutu’s corrugated cardboard and Z-cardboard solutions are customized to the needs of different sectors. Thanks to our production flexibility, we are here for you, from small batches to large-volume wholesale orders.
Sector
Problem
Z Cardboard Solution
Shipping & Logistics
Separate stock for each size, delivery confusion.
It offers on-site cutting capabilities; eliminates the need for different sizes, reduces inventory burden and operational complexity.
Furniture Manufacturing
Corner and surface damage in large-volume products.
The product-specific box design minimizes corner and surface damage. HE wave material provides an optimal solution, especially in modular furniture.
Automotive & Metal
Load bearing capacity in heavy spare parts logistics.
In heavy spare parts logistics requiring high strength, it provides durability performance in accordance with ECT and BST standards.
E-commerce
A different box for each product — to reduce waste and cost.
Zkarton enables the production of custom boxes for specific products; its fast cutting reduces waste and lowers costs.

The Same Standard in Every Party

In our ISO-certified production facility, every batch of raw materials and finished products undergoes comprehensive testing.

ECT — Edge Crushing Resistance

Corrugated cardboard edge load-bearing and stacking capacity (kN/m)

BST - Explosion Resistance

Pressure required for hydraulic blasting (kgf/cm²)

COBB - Moisture Resistance

The amount of water absorbed by 1 m² of paper — an indicator of moisture resistance.

FCT — Surface Crushing Strength

Groove flexibility and shock absorption capacity (kPa)

Weight Test

The water content of the paper — its durability during storage and transport.

Moisture Test

The water content (%) of the paper — an indicator of its durability under storage and transport conditions.

These tests are concrete evidence that Haskutu meets supplier audit requirements in its B2B procurement processes. You can submit your technical specification requests during the bidding phase.

Frequently Asked Questions

What is the difference between Z-shaped cardboard and standard corrugated cardboard?
Corrugated cardboard is a general material name; it can be produced in sheet, box, or roll form. Z-Cardboard, on the other hand, is a special form of corrugated cardboard that is folded into a Z shape during production instead of being cut to size, resulting in long, accordion-like lengths. It allows you to package products of different sizes with a single stock item and offers up to 30% savings in warehouse space.

The minimum order quantity for Z-shaped cardboard is 2,000 m². This may vary depending on the corrugated profile and order configuration.

We manufacture in B, C, H, BC, EB, and HE wave profiles. The length per pallet is as follows: H (650 m) — B (480 m) — HE (400 m) — EB (325 m) — C (360 m) — BC (212 m).

Yes. With our flexographic printing option, we offer printing in up to 2 colors. The delivery time for printed orders is usually 7–10 business days.
Yes. We deliver directly from our factory in Sincan, Ankara, to all provinces of Türkiye through our logistics network.
ECT (Edge Crush Test) measures the edge load-bearing capacity of corrugated cardboard, while BST (Bursting Strength Test) measures its resistance to bursting under hydraulic pressure. Our production, certified with ISO 9001, ISO 14001, and ISO 45001, meets these standards.

Get a direct quote from the factory.

For a direct price quote, please contact us through the channels below.
Our team will contact you within 24 business hours.
